Tool Holder: SDS-Max
Battery chemistry: Li-Ion, Battery Voltage: 18/54 V
Battery Capacity: 9.0 Ah
Impact energy (EPTA 05/2009): 6.1 J
Load Speed: 540 rpm
Blows per Minute: 3150 bpm
Max. Drilling Capacity [Concrete]: 40 mm
Max. Drilling Capacity [Breakthrough bit]: 65 mm
Max. Drilling Capacity [Core bit]: 100 mm
Length: 502 mm, Height: 263 mm, Width: 108 mm, Weight: 5.4 kg
Hand/Arm Vibration – Hammer drilling into concrete: 9.4 m/s²
Uncertainty K 1 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Chiselling: 8.5 m/s²
Uncertainty K 2 (Vibration): 1.5 m/s²
Sound Pressure: 96 dB(A), Sound Pressure Uncertainty: 3 dB(A)
Sound Power: 107 dB(A), Sound Power Uncertainty: 3 dB(A)
